DD Audio POWER TUNED 1500 Series Subwoofers

THE NOT SO ENTRY LEVEL SUBWOOFER

Description
DD Audio 1500 Series Subwoofer

The 1500 Series are entry-level priced USA made subwoofers that will outperform most other brands flagship models. They’re equipped with EROM surrounds, multi-layer suspensions, light weight cones, and 800 degree thermoset voice coils. The soft parts are driven via high energy motors that feature our Free Flow cooling system and Faraday shorting rings. This sub is a perfect solution for medium power applications where supreme quality is a necessity.

The 1500 Series comes standard with an oversized dry finish black composite dust cap, red logo, and treated pulp cone, but it can be optioned out with alternative composite dust caps, composite cones, powder coated frames, supercharging, and a multitude of logo options to give your sub a personalized look and/or added performance for a specific application.


SPECS

MODEL 1508A 1510A 1512A
Driver Size 8″ 10″ 12″
Watts RMS 300 – 600 300 – 600 300 – 600
Peak Power 2400 2400 2400
VCD 2 2 2
Impedance D2 / D4 D2 / D4 D2 / D4
Piston Dia – in 6 1/2 8 1/2 10
Fs – Hz 44.41 43.74 31.63
Qms 6.224 4.859 7.618
Qes 0.960 1.015 1.083
Qts 0.832 0.839 0.948
Vas – liters 6.201 15.007 43.55
Xmech – mm 48 48 48
Xmax – mm 14 14 14
Frame OD – in 8 3/16 10 1/8 12 1/4
Frame OD w/Gasket – in 8 7/16 10 3/8 12 1/2
Mounting Diameter – in 7 3/16 9 1/8 11 1/8
Mounting Depth – in 5 9/16 5 3/4 6 5/16
Motor Diameter – in 5 1/4 5 1/4 5 1/4
Motor Depth – in 2 13/16 2 13/16 2 13/16
Woofer Displacement – cu ft 0.05 0.06 0.08
Shipping Weight – lbs 16 16 18
Sealed Enclosure – cu ft N/A N/A N/A
Ported Enclosure – cu ft 0.75 – 1.25 1.25 – 1.5 1.75 – 2.75
Price (USD) 339 329 339
